Product information
Model 8150
Utensil Washer 8150: A big and efficient machine for the industry
Options
Very large wash volume:
H (870 mm) * W (1340 mm) * D (800 mm)
- Automatic lid opening system
- Industrial version.
- Individual adaptation possible.
Capacity
| Cycle times | 2+4+6 min |
| Euronorm crates 400 × 600 | 6 pcs. |
| Plates 600 × 400 | 60 pcs. |
| Plates 600 × 460 | 38 pcs. |
| Plates 600 × 800 | 38 pcs. |
| Gastronorm trays 500 × 500 | 2 pcs. |
| 60 L bowl H 511 × ø 575 | 2 pcs. |
| 80 L bowl H 515 × ø 645 | 2 pcs. |
| 100 L bowl H 558 × ø 685 | 1 pcs. |
Electrical
| Voltage | 3N ~ 50 Hz 400/230 V + PE |
| Total power | 18.5 kW |
| Fuse | 32 A |
| Pump power | 2 x 2.7 kW |
| Heating element, wash tank | 6 kW |
| Heating element, rinse tank | 2 x 6 kW |
| Rinse pump, motor | 0.55 kW |
| Motor protection | Yes |
| Wash pump capacity | 2 x 950 |
Water and steam
| Wash temperature | 55 °C |
| Rinse temperature | 85 °C |
| Wash tank | 165 l |
| Rinse tank | 31 l |
| Wash pressure | 0.9 - 1.9 bar |
| Rinse pressure | 1.1 bar |
| Water consumption per wash | 16 l |
Installation
| Other voltage on request | More than 8°dH we rec- |
| Max. power / main fuses | 18.5kw |
| Heating elements | 32A |
| Power cable (standard) | 2x6.0kW + 1x6kW |
| Water connection, dimension | 5x4² x 2500mm |
| Water connection, pressure | 1/2” RG, 0.7-6dyn bar |
| Water connection, temperature | 1/2” x 1600mm, 50°C. |
| Drain dimension | Ø40 mm. |
| Noise level | 70 dB(A) |
| Air consumption during blow-off | Ca. 470Nm3/h ved 5.5 bar efter regulator |
Dimensions and weight
| Width | 1700 mm |
| Depth | 1025 mm |
| Height | 1931 mm |
| Height, hood open | 2600 mm |
| Wash area (W × H × D) | 1340 x 870 x 800 mm |
Packaging
| Gross weight | 350 kg |
